Model -SFDP2-028-045-33 – DC Diaphragm Pump 24v Seaflo

The 33-Series is our general-duty on-demand positive displacement pump. It provides reliable performance in high water flow, moderate pressure applications. This 3-chamber diaphragm pump provides up to 3.0 gallons per minute and is capable of self-priming up to 6vertical feet, and can run dry without damage. Serves 3 or more 1/2” (13 mm) outlets. This automatic demand water system pump has a built-in pressure switch, which automatically starts and stops when the faucet is opened and closed. They’re easy to install, service and winterize.

Voltage:12V/24V/115V/220V

Open Flow:2.8-3.0GPM / 10.6-11.3LPM

Shut-off Pressure:45PSI / 3.1BAR

Priming Capabilities:6 feet (1.8 m) suction lift

Max Recommended Temperature:140° F (60° C)Max.

Material:EPDM(Valves) / Santoprene(Diaphragm)

Ports:1/2″-14 MNPT
